Archimedes cam device.so that the top of glove finger is knitted round and smooth and the whole glove looks nicer.Meanwhile,it can knit thinner gloves

by its improved spare parts and advanced component.

Main Character:

Computer control for whole-process,key board operation.
Steady performance,convenient operation,high control-ratio
Archinmedes cam device and inlaying type neddle bed&sinker device makes the glove look nicer.
With double color,air-spaying device,gloves become high-grade.
With auto-stop device for thread-break,count improper download,electrical machinery overload etc,it reduces damage&loss in knitting.
Electromagnet over-temperature protection,short circuit protection,to ensure the normal operation of computer security.
Adopting electronic-auto-control oil-providing device and keep lubricate character.

Main Technology Parameters(Example of 10G)

Gauge: 10G、12G、15G
Highest rotate speed :Longway 140rpm shortway 280rpm
Voltage, power :Three-phase ＆ single-phase 220V、250W

Output/Set : 140 pairs/8hour

Control Sets:  12-18Set/person

Dimension: 1230×680×1700mm（L×W×H）

Weight: 250千克（Kg）
